2RB910-7AH37
50Hz
| Stage: | single | Phase: | 3AC |
| Frequency(HZ) : | 50 | Output(KW): | 18.5 |
| Voltage(V): | 345-415∆/600-720Y | Current(A): | 37.0∆/21.0Y |
| Air flow(m3/h): | 1050 | Vacuum(mbar): | -360 |
| Pressure(mbar): | 460 | Sound(dB(A): | 74 |
| Weight(kg): | 126 | Inlet/outlet(inch): | G4.0 |
| Dimension(mm): | 644*550*624 |
60Hz
| Stage: | single | Phase: | 3AC |
| Frequency(HZ): | Output(KW): | 21.3 | |
| Voltage(V): | 380-480∆/660-720Y644*550*624 | Current(A): | 39.0∆/22.5Y |
| Air flow(m3/h): | 1250 | Vacuum(mbar): | -380 |
| Pressure(mbar): | 420 | Sound(dB(A): | 78 |
| Weight(kg): | 126 | Inlet/outlet(inch): | G4.0 |
| Dimension(mm): | 644*550*624 |
